XPG

XPG CORE REACTOR ATX Fully Modular Power Supply - 850 Watt 80 Plus Gold Certified | 22 Total Connectors | Low Noise PSU

$129.99
MPN
COREREACTOR850G-BKCUS
UPC:
842243019223
Condition:
New
Availability:
Available
ATX Version: Intel ATX 12V v2.52
Protections: OCP / OVP / UVP / OPP / SCP / OTP / NLO / SIP
Certification: CE / UKCA / CB / FCC (IC) / EAC / CCC / TUV / cTUVus / RCM / NOM / BSMI / BIS / KC
PFC: 0.99
Input Voltage: 100V-240V
Input Current: 10-5A
Input Frequency: 47Hz-63Hz
Operating Temperature: 50 deg. C
Fan Size: 12cm
Fan Bearing: FDB (Fluid Dynamic Bearing)
Fan Speed: 2,400 RPM
MTBF: 100K hours at full load
Noise Level @ 20% 850W: 11.2dB(A)
Noise Level @ 50% 850W: 11.3dB(A)
Noise Level @ 100% 850W: 24.7dB(A)
Warranty: 10 Year
Delivery by ,
If ordered within hours and minutes
Not Shipping to ?
5 customers are viewing this product

CORE REACTOR

The XPG CORE REACTOR is a modular, 80 Plus Gold power supply unit equipped with 100% Japanese capacitors. Combined with Line Level Control (LLC) resonant topology, it is power-efficient, reliable and makes creating a tidy build easy.

80 Plus Gold Certified

The 80 Plus Gold certified XPG CORE REACTOR gives you 90% efficiency at 50% load. It comes in 650W, 750W, and 850W for different needs.

Cybenetics LAMBDA / ETA Certified

XPG CORE REACTOR SERIES is certified by Cybenetics for its efficiency and noise level, scoring at the top of its category in both ETA and LAMBDA standards.

Intelligent Fan-Curve

Intelligent fan-curve provides near-quiet operations, even when at full power load. The fan control starts at a low 3.3v, 660rpm ± 10%, and remains at this speed until surpassing 50% load, prolonging the lifespan of the fan and the power supply unit.

Compact and Modular

The XPG CORE REACTOR is compact in size due to the combination of high-quality components, a well-thought-out layout, and a new manufacturing process. What's more, its modular design reduces cable clutter and simplifies system building.

Premium Japanese Capacitators

Equipped with All 105°C Japanese capacitors, the XPG CORE REACTOR provides you with reliability and stability. The XPG CORE REACTOR’s DC voltage is maintained within ±2% and reduces ripple and noise by up to 35% for enhanced dependability.

Industrial-Grade Protection

The XPG CORE REACTOR comes with an array of protection mechanisms for peace of mind and backed by a 10-year warranty.

  • Over Current Protection (OCP)
  • Over Voltage Protection (OVP)
  • Under Voltage Protection (UVP)
  • Over Power Protection (OPP)
  • Short Circuit Protection (SCP)
  • Over Temperature Protection (OTP)
  • No Load Operation (NLO)
  • Surge & Inrush Protection (SIP)

ATX Version: Intel ATX 12V v2.52
Protections: OCP / OVP / UVP / OPP / SCP / OTP / NLO / SIP
Certification: CE / UKCA / CB / FCC (IC) / EAC / CCC / TUV / cTUVus / RCM / NOM / BSMI / BIS / KC
PFC: 0.99
Input Voltage: 100V-240V
Input Current: 10-5A
Input Frequency: 47Hz-63Hz
Operating Temperature: 50 deg. C
Fan Size: 12cm
Fan Bearing: FDB (Fluid Dynamic Bearing)
Fan Speed: 2,400 RPM
MTBF: 100K hours at full load
Noise Level @ 20% 850W: 11.2dB(A)
Noise Level @ 50% 850W: 11.3dB(A)
Noise Level @ 100% 850W: 24.7dB(A)
Warranty: 10 Year
